Galvalume
Galvalume is produced through the hot-dip process and is backed up with an industry leading warranty ranging from 40 to 60 years based on coating weight and surface treatment.



Galvalume PlusTM is a coated steel sheet that combines the excellent corrosion resistance of a GalvalumeTM  coating with a clear, organic surface treatment. The resin coating is applied over both sides of the GalvalumeTM sheet as a final protective layer. The result is an enhanced product with superior attributes for architects, product manufacturers, installers and building owners. Galvalume PlusTM can be roll formed dry with no lubricants and delivered to the jobsite dry with no oil on the surface. It resists fingerprinting during handling and installation, maintaining its "brand new" appearance longer.

Qualities  Commercial Steel -- ASTM A792/A792M  Structural Steel -- ASTM A792/A792M  High Temperature Steel -- ASTM A792/A792M (Galvalume only)  Special Forming Steel  Helical Steel Culvert  Standard Coating Weights (both sides)  AZM150 150 g/m2 minimum triple spot  AZM165 165 g/m2 minimum triple spot  AZM180 180 g/m2 minimum triple spot  CSP Coating: AZ210 210 g/m2 minimum triple spot

Product Parameter：



Echnical Standard EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653  JIS G3302,ASTM A653M,EN10327,DIN17162,EN 10142,EN10292,
Steel Grade

Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490

,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQCR80(550), CQ, FS, DDS,

EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type Coil/Sheet/Plate/Strip
Thickness 0.12-6.00mm,or customer's requirement
Width 600mm-1500mm, according to customer's requirement
Type of Coating Hot Dipped Galvanized Steel(HDGI)
Zinc Coating 30-275g/m2
Surface Treatment Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U) galvanized，PVC，black and color painting，transparent oil，anti rust oil
echnical Standard EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653  JIS G3302,ASTM A653M,EN10327,DIN17162,EN 10142,EN10292,
Steel Grade

Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,SGH540, SGCD1,

 SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQCR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230),

 SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Thickness 0.12-6.00mm,or customer's requirement
Width 600mm-1500mm, according to customer's requirement
Type of Coating Hot Dipped Galvanized Steel(HDGI)
Zinc Coating 30-275g/m2
Surface Treatment Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U) galvanized，PVC，black and color painting，transparent oil，anti rust oil


GalvalumeTM steel is used for industrial & commercial roofing, agricultural buildings, light steel framing, construction tubular, and pre-engineered buildings
